| Part Number | DC BreakdownVo ltage(VBR)@100V/s(V) | Tolerance of VBR(V) | Impulse Spark-overVoltage@1KV/μs(V) | Arc Voltage (Va)@1A(V) | Impulse Discharge Current@8/20μs(KA) | Insulation Resistance(GΩ) | @ DC(V) | Capacitance CO 0.5VDC@1MHZ(pF) | Size L*W*H(mm) | 搜索 | |
| BGO1001A05-LC2 | 1000 | ≥800 | ≤2000 | 〜60 | 5 | ≥1 | 100 | ≤1.5 | φ8x7.0 | ||
| B5G470L | 470V | 376-564 | ≤850V | ～15V | 5KA | ≥1 | 100 | ≤1pF | φ5.5*6 | ||
| B5G600L | 600V | 480-720 | ≤950V | ～15V | 5KA | ≥1 | 100 | ≤1pF | φ5.5*6 | ||
| B5G800L | 800V | 640-960 | ≤1600V | ～15V | 5KA | ≥1 | 100 | ≤1pF | φ5.5*6 | ||
| B5G3600 | 3600V | 2880-4680 | ≤4700V | ～15V | 3KA | ≥1 | 100 | ≤1pF | φ5.5*6 | ||
| B8G600M | 600V | 480-720 | ≤1400V | ～15V | 10KA | ≥1 | 100 | ≤1.5pF | φ8*6 | ||
| B8G3600L | 3600V | 2880-4320 | ≤6000V(@1.2/50μs 6kV) | ～15V | 5KA | ≥1 | 100 | ≤1.5pF | φ8*6 | ||
| BGO6000A03-LB2 | 600 | ≥480 | ≤1500 | / | 3 | / | / | ≤1.5 | Φ5.5x6.0 | ||
| BGO6000A10-LC2 | 600 | ≥480 | ≤1500 | 〜40 | 10 | ≥1 | 100 | ≤1.5 | φ8x7.0 | ||
| BGO1001A10-LC2 | 1000 | ≥800 | ≤2500 | 〜60 | 10 | ≥1 | 100 | ≤1.5 | φ8x7.0 |
