二极贴片系列 > 百家欧赔 (GDT) >
  Part Number DC BreakdownVo ltage(VBR)@100V/s
(V)		Tolerance of VBR(V)Impulse Spark-over
Voltage@1KV/μs
(V)		Arc Voltage (Va)@1A(V)Impulse Discharge Current@8/20μs
(KA)		Insulation Resistance
(GΩ)		@ DC
(V)		Capacitance CO 0.5VDC@1MHZ(pF)Size L*W*H(mm) 搜索

BS401N 400280-520≤1100V～8V0.5kA≥1100≤0.63.2*1.6*1.6
BC091N-H 9063-117≤650～8V3KA≥1100≤1pF4.5*3.2*2.7
BC151N 150105-195≤750～8V2KA≥1100≤1pF4.5*3.2*2.7
BZ401M 400360-580≤950V～10V1kA ≥1100≤1.03.2*2.5*2.5
BZ091N 9063-117≤700～81≥150≤0.53.2*2.5*2.5
BA151N 150105-195≤750～8V1KA≥1100≤1pF4.5*3.2*2.7
BA201N 200140-260≤750～8V1KA≥1100≤1pF4.5*3.2*2.7
BA301N-D 300210-390≤750～15V1KA≥1100≤1pF4.5*3.2*2.7
BA401N-D 400340-550≤750～15V1KA≥1100≤1pF4.5*3.2*2.7
BS201N 200140-260≤850V～10V0.5KA≥1100≤0.63.2*1.6*1.6
BA601N 600420-780≤1200～15V1KA≥1100≤1pF4.5*3.2*2.7
BC201N 200140-260≤800～8V2KA≥1100≤1pF4.5*3.2*2.7
BC301N-D 300210-390≤750～15V2KA≥1100≤1pF4.5*3.2*2.7
BC401M 400360-560≤950～15V2KA≥1100≤1pF4.5*3.2*2.7
BC601N 600420-780≤1200～15V2KA≥1100≤1pF4.5*3.2*2.7
BF091M 90V72-108≤650V～8V5KA≥1100≤1.0pF4.2*5.0*5.0
BF231M 230V184-276≤700V～8V5KA≥1100≤1.0pF4.2*5.0*5.0
BF351M 350V280-420≤750V≥15V5KA≥1100≤1.0pF4.2*5.0*5.0
BF601M 600V480-720≤1200V～8V5KA≥1100≤1.0pF4.2*5.0*5.0
BF801M 800V640-960≤1600V～15V3KA≥1100≤1.0pF4.2*5.0*5.0
BF102M 1000V800-1200≤1800V～15V3KA≥1100≤1.0pF4.2*5.0*5.0
BF122M 1200V960-1440≤2000V～15V3KA≥1100≤1.0pF4.2*5.0*5.0
BM091M 90V 72-108 ≤600V ～8V20KA ≥150≤1.5pF8.3*8.3*6
BM351M 350V 280-420≤650V ～15V20KA ≥1100≤1.5pF8.3*8.3*6
BM471M 470V376-564≤850V ～15V20KA≥1100≤1.5pF8.3*8.3*6
BM601M 600V 480-720≤950V ～15V20KA≥1100≤1.5pF8.3*8.3*6
BM801M 800V640-960≤1200V ～15V20KA≥1100≤1.5pF8.3*8.3*6
BM362M 3600V2880-4320≤5500V
(@1.2/50μs 6kV)		～30V5KA≥1100≤1.5pF8.3*8.3*6
BF151M 150V120-180≤420V～13V5KA≥1100≤0.8pF4.2*5.0*5.0
BA301N 300210-390≤800～8V1KA≥1100≤1pF4.5*3.2*2.7
BZ201M 200160-240≤800～81≥1100≤0.53.2*2.5*2.5
BZ301M 300240-360≤850～81≥1100≤0.53.2*2.5*2.5
BX151N 150105-195≤650～103≥150≤0.64.2*3.5*3.5
BX091N 9063-117≤650～103≥150≤0.64.2*3.5*3.5
BX201N 200140-260≤750～103≥1100≤0.64.2*3.5*3.5
BX301N 300210-390≤850～103≥1100≤0.64.2*3.5*3.5
BG091N 9063-117≤650〜101≥150≤0.52.9x2.1x1.9
BG201N 200140-260≤750〜101≥1100≤0.52.9x2.1x1.9
BG301N 300210-390≤850〜101≥1100≤0.52.9x2.1x1.9
BG401N 400280-520≤1000〜101≥1100≤0.52.9x2.1x1.9
BL091N 9063-117≤650〜101≥150≤0.52.9x2.1x1.9
BL151N 150105-195≤700〜101≥1100≤0.52.9x2.1x1.9
BL201N 200140-260≤750〜101≥1100≤0.52.9x2.1x1.9
BL301N 300210-390≤850〜101≥1100≤0.52.9x2.1x1.9
BL401N 400280-520≤1000〜101≥1100≤0.52.9x2.1x1.9
BZ801M 800640-960≤1400〜101≥1100≤1.03.2x2.5x2.5
BX401N-D 400370-560≤750≥183≥1100≤0.64.2x3.5x3.5
BN075M 7560-90≤600〜85≥150≤0.55.5x4.0x4.0
BN091M 9072-108≤600〜85≥150≤0.55.5x4.0x4.0
BN151M 600480-720≤1200〜155≥1100≤0.55.5x4.0x4.0
BN801M 800640-960≤1400〜155≥1100≤0.55.5x4.0x4.0
BN202M 20001600-2400≤3000〜153≥1100≤0.55.5x4.0x4.0
BN252M 25002000-3000≤3500〜253≥1100≤0.55.5x4.0x4.0
BN302M 30002400-3600≤4000〜253≥1100≤0.55.5x4.0x4.0
BN362M 36002880-4320≤4800〜303≥1100≤0.55.5x4.0x4.0
BN362M-1 36002880-4320≤4800〜303≥1100≤0.55.5x4.2x4.2
BF421M 420336-504≤750≥155≥1100≤1.04.2x5.0x5.0
BF471M 470376-564≤850〜155≥1100≤0.84.2x5.0x5.0
BJ091M 9072-108≤600〜105≥150≤0.55.5x5.5x5
BJ091M-1 9072-108≤600〜1010≥150≤1.05.4x5.4x5
BM152M 15001200-1800≤2500〜1510≥1100≤1.58.3x8.3x6
